| Robotic arm parameters | |
| Power Supply/Power | 380V±5%, three-phase four-wire |
| Air Supply Usage | For grippers and clamps: Pressure 0.8 Mpa, Air flow rate 0.3 m³/min For suction cups: Pressure 0.8 Mpa, Air flow rate 0.6 – 1.1 m³/min, Total gas storage capacity > 600 L |
| Equipment Dimensions | Total height 3 m, Rotation coverage radius 2.8 m, Floor area:6×6 m² |
| Cable Length | 3m (robot body to control cabinet) |
| Max Palletizing Height | ≤2300mm (grippers/clamps); ≤2400mm (suction cups) |
| Applicability | 60kg products, including bags, cartons, sheets, blocks, or similar packaging |
| Palletizing Efficiency | 400 – 500 times/hour (in double – grab and double – place mode), 800 – 1000 pieces/hour |
| Power Consumption | Manipulator body15 kW Shaping conveyor/positioning conveyor1.5 kW |
| Pallet Size | ≤1400×1600mm (including actual stacking pattern) |
| Customizable | Actual arm span, overall load capacity, number of joint axes Subsequent Upgrades |
| Upgradable | Vision Recognition, Pallet Conveyor Integration, Ton Bag Lifting Mechanism, Anti-Collapse Interlocking Mechanism |
HFMR-200S
